Real‑Time Crypto Discovery Meets AI Guidance

Engineering Coinflux Crypto Assets Research Market & Exchange Hub
Main visual

1. Client Snapshot

Coinflux is a one‑stop crypto intelligence and trading gateway. Beyond ranking 12 000 + assets with real‑time charts, it layers on AI‑powered Q&A, side‑by‑side exchange comparisons, and direct buy flows—bridging newcomers and seasoned traders alike.

clint_snapshot

Impact

  • < 100 ms average ticker latency worldwide (dataplane p95).
  • Serves 1.2 M websocket messages‑per‑minute during peak volatility with 99.99 % uptime.
  • AI answers reduce support tickets by 63 % and keep cost per answer at $0.003 via caching.
  • Exchange comparison drives 18 % higher click‑through to partner on‑ramps versus baseline widgets.
  • Serverless footprint lowers infra spend 40 % compared with container prototype.

2. The Challenge

  • Streaming precision — price tiles, charts, and heat‑maps must update every 5 s without page reloads or data jitter.
  • AI at scale — ChatGPT answers thousands of open‑ended queries daily; the prompt pipeline needed guard‑rails and caching to keep unit costs low.
  • Exchange aggregation — pull fees, liquidity, and KYC rules from 15 + exchanges and normalise the data for fair comparisons.
  • Fiat on‑ramp security — integrate third‑party checkout while enforcing KYC/AML and shielding PCI data.
  • Traffic volatility — bull‑run surges can triple concurrent websocket sessions; infra had to autoscale within 60 s with zero cold‑start lag.

5. Services Delivered

  • Full‑stack architecture & development
  • Real‑time data streaming & caching
  • AI integration (OpenAI GPT‑4)
  • Multi‑exchange & payments integration
  • DevOps & observability
  • Security, KYC/AML & compliance automation

3. Our Solution

PillarImplementation Highlights
Event‑driven architectureNode.js services on AWS Lambda & API Gateway; AWS AppSync (GraphQL websockets) streams delta updates < 100 ms p95.
Data ingestion & cachingCoingecko REST + Websocket feeds funnel through Kafka → Redis Streams; snapshot API cached behind CloudFront for 95 % hit rate.
AI query engineEdge worker wraps OpenAI GPT‑4; conversation context & rate limits stored in DynamoDB; answered queries cached in Redis with embeddings‑based similarity.
Exchange connector hubCustom adapters poll Binance, Coinbase, Kraken, KuCoin, etc.; cron diff jobs reconcile fee tables hourly and raise alerts on drift.
Payments & complianceTransak / MoonPay widgets embedded via secure iframe; webhook‑verified orders flow into a KYC micro‑service (SumSub) before marking transactions complete.

6. Tech Stack

Node.jsTypeScriptAWS LambdaAPI GatewayAppSync (GraphQL)KafkaRedisDynamoDBOpenAICoingecko APITransakMoonPayDockerCloudFront

By uniting low‑latency streams with conversational AI, Coinflux turns crypto data into actionable insight—helping traders decide, compare, and buy in seconds.
